F-22 Squad Ops Hangar

Elmendorf AFB, Anchorage, Alaska

Door Configuration:

6-Leaf, Bi-Parting Door System

Opening:

Two 175' wide x 24' high

Description:

Planned for joint use by the Air Force and Air National Guard, this Corps of Engineers hangar project is the largest in the new F-22 program at Elmendorf AFB. Davis Constructors & Engineers Inc. worked on the facility, which consists of a 35,000 sq. ft. six bay maintenance hangar with an adjacent three story 49,000 sq. ft. squadron operations facility featuring two 175’ x 24’, 6-leaf, bi-parting Northern door systems from Norco. These doors are also properly sealed and insulated for the brutal Alaskan weather.

Features:

3" exterior insulated panel
Insulated translucent panels
No portion of bottom rails are exposed to elements when doors are closed
Dual weather seals for maximum energy efficiency and minimal air infiltration
Doors are controlled from inside and stack on the interior of the building
For added safety, electrical door interlock switch disables the drive door when personnel door is open
